Hikvision iDS-E08HQHI-XB

Detailní popis produktu

• Detekce pohybu 2.0
• Human/Vehicle Analysis

  Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

  Quick search by object or event type is supported;

• Ochrana perimetru
• Human/Vehicle AnalysisUp to 4-ch

• Video and Audio
• IP Video Input

  2-ch

  Up to 6 MP resolution

  Support H.265+/H.265 IP cameras

• Analogový video vstup

  8-ch

  BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

• HDTVI Input3K@20 fps, 5 MP@20 fps, 4 MP@30 fps, 4 MP@25 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps, 720p50, 720p60
• AHD Input5 MP@20 fps, 4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
• HDCVI Input5 MP@20 fps, 4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
• CVBS InputSupport
• HDMI Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• VGA Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• Video Output ModeHDMI/VGA simultaneous output
• Zvukový vstup8-ch via coaxial cable
• Audio výstup1-ch via HDMI
• Synchronous Playback4-ch

• Recording
• Video kompreseH.265 Pro/H.265
• Rozlišení kódování

  When 1080p Lite mode is not enabled:

  5MPLite/3KLite/4MPLite/1080p/720p/WD1/4CIF;

  When 1080p Lite mode is enabled:

  5MPLite/3KLite/4MPLite/1080p Lite/720p/WD1/4CIF;

• Snímková frekvence

  Main stream:

  When 1080p lite mode not enabled:

  For 3K stream access:

  3K LITE @12FPS；4 MP lite@15 fps; 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

  For 5MP stream access:

  5MP LITE @12FPS；4 MP lite@15 fps; 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

  For 1080p stream access:

  1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

  For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

  When 1080p Lite mode enabled:

  5MP/3K lite/ 4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps (P)/30fps (N)

• Video BitrateAccording to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.
• Typ streamu

  Video, Video & Audio

  Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.

• Audio kompreseG.711u
• Audio Bitrate64 Kbps

• Síť
• Total Bandwidth

  96 Mbps

  Incoming bandwidth: 8 Mbps

• Vzdálené připojení64
• Síťový protokolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
• Síťové rozhraní1, RJ45 10/100 Mbps self-adaptive Ethernet interface

• Auxiliary Interface
• Kapacita

  Built-in 1024 GB eSSD (960 GB available)

  Note:

  M-SATA interface, capable of plugging and upgrading capacity.

  The device can store about 2 weeks videos for 8-ch analog cameras (default parameters), this estimation is for reference only.

• Vstup/výstup alarmuOPTIONAL 4/1
• USB rozhraníRear panel: 2 × USB 2.0

• Všeobecné
• Zdroj napájení12 VDC, 1 A
• Spotřeba≤ 8.2 W (with eSSD)
• Pracovní teplota-10 °C to 45 °C (14 °F to 113 °F)
• Pracovní vlhkost10% to 90%
• Rozměry (Š × H × V)170 × 121.6 × 46 mm (6.7 × 4.79 × 1.81 inch)
• Váha≤ 0.6 kg (with eSSD, 1.1 lb.)
