Hikvision DS-KIS704EY/Aluminium

Detailní popis produktu

• Dveřní stanice/Parametry systému
• ProcesorEmbedded Processor
• ROM4 GB
• RAM256 MB
• Operační systémEmbedded Linux operation system

• Door station/Screen parameters
• Screen sizeNA
• ŘešeníNA
• TypNA
• Provozní metodaNA

• Dveřní stanice/Parametry videa
• Supplement lightSupplement light Low illumination, IR supplement lights
• Řešení2MP
• Objektiv1
• Wide dynamic range (WDR)Support
• FOVHorizontal: 133°, Vertical: 82°
• Standard komprese videaH.264

• Dveřní stanice/Parametry zvuku
• Audio inputBuilt-in omnidirectional microphone
• Audio outputBuilt-in loudspeaker
• Nastavení hlasitostiAdjustable
• Standard komprese zvukuG.711 U, G.711 A
• Přenosová rychlost komprese zvuku64 Kps
• Kvalita zvukuNoise suppression and echo cancellation

• Door station/Capacity parameters
• Linked indoor station capacityMax.99
• Sub door station capacity16

• Dveřní stanice/Síťové parametry
• Wireless network10/100 Mbps self-adaptive through 2-wire interface
• Wi-FiOnly AP mode for configuration

• Dveřní stanice/Rozhraní zařízení
• RS-4852 (RS485 out for Hikvision's sub module communication, RS485 for reservation)
• Lock control2 (1 relay, max to 30 VDC, 2 A；1 DC pulse，20V 4A impulsive，300 mA holding current，30 ohm max )
• Tlačítko Konec1
• Vstup dveřního kontaktu1
• Alarm input2（supports Exit button or Door contact input）
• Power supply input12VDC input
• TAMPER1
• Ladění portu1
• Two-Wire1
• DIP Switch6 decimal DIP switch

• Dveřní stanice/Obecné
• Tlačítko0-2（Flexible adjustment）
• Indikátor4 LED lights(Opening door、Calling、Intercom、In use）
• Power supply48V，Powered by distributor DS-KAD7060EY or 12VDC
• Power consumption≤ 6 W
• Working temperature-40° C to 60° C (-22° F to 140° F)
• Working humidity10% to 90%
• Prostředí aplikaceOutdoor
• Rozměry (Š × V × H)99.5 mm × 98.5 mm × 35 mm (3.92" × 3.88" × 1.37")
• InstalaceSurface mounting & flush mounting
• Ochranná úroveňIP65 IK08
• JazykEnglish, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch , Spanish, Romanian, Estonian, Croatian, Slovenian, Serbian, Ukrainian, Portuguese

• Video Audio Distributor/Rozhraní
• Power interface48VDC
• Dvouvodičové rozhraní6("IN""OUT" for casacading, CH1-CH4 for Door station and Indoor station)

• Distributor zvuku a videa/Obecné
• Power supply48VDC
• Power consumptionCH1＜30W，CH2＜30W，CH3＜30W，CH4＜30W；MAX Total 30W
• Working temperature-10 °C to 5 °C (14 °F to 131 °F)
• Working humidity10% to 90% (no-condensing)
• Rozměry (Š × V × H)143.7 mm × 92.4 mm × 65.9 mm (5.66" × 3.64" × 2.59")
• InstalaceDIN rail installation
• Indicators

  6 Signal indicators;

  1 Power indicator
